FALKO 3D Magnification Wireless Medical Visor with 4K Camera and Light

FALKO 3D Magnification Wireless is a medical AR headset for dental, medical and surgical use. Connected to the practice PC, it brings the magnified operating field and on-screen content — CBCT, intraoral scans, guided surgery plans and clinical software — into your line of sight.

View the operating field and PC content in the headset

It shares FALKO X5’s autofocus camera and LED light but is built differently: rather than working stand-alone like X5, it connects to the practice’s main PC. The camera sends the live feed to the main PC via a 5 m USB cable, and the wireless headset displays everything on the screen. View your point-of-view live feed, CBCT, intraoral scans, records and clinical software in the headset, side by side if needed, without turning to the monitor or changing posture. Viewing is available in 2D or 3D Side-by-Side mode, standard or see-through.

Continuous autofocus and 6×–4× magnification

Focus adjusts automatically over the 25–50 cm working distance range. Magnification varies with distance: 6× at 25 cm, 5× at 40 cm and 4× at 50 cm. Focus, zoom, exposure and brightness can also be adjusted manually in MagnoCam. The integrated LED light delivers a circular spot at 24,000 lux, with adjustable intensity and a filter to prevent premature composite curing.

MagnoCam: capture, document and share

MagnoCam displays the live feed and lets you capture still images and record video in the patient gallery. Images, videos and annotations are organised in the patient imaging record, with archive export and synchronisation options. The 3D button activates Side-by-Side viewing for the FALKO headset. The included TWAIN driver enables frame capture in compatible practice management software. The PC’s video conferencing and streaming applications allow live video and shared content to be broadcast to colleagues, assistants and students.

Applications in clinical practice, surgery and education

FALKO 3D Magnification combines observation of the operating field, access to PC content and clinical documentation for dental, medical and surgical work. Dental applications include restorative dentistry, endodontics, prosthodontics, periodontics, implant dentistry and oral surgery. In medical practice, the magnified camera view supports observation in dermatology and outpatient surgery. Photos, video and PC-based sharing also support case documentation and professional education.

FALKO 3D Magnification technical specifications

For full specifications and feature details, see the attached PDF.
