Tecnomed Surgical MULTILED-H operating lamp, LED 160,000 Lux, single head ceiling mount with FHD HDMI camera
Available on request
The Surgical multiLED-H ceiling-mounted operating lamp, single head with 160,000 Lux light output, is designed to provide reliable illumination for dental and multidisciplinary surgical applications.
The integrated Full HD camera allows procedures to be recorded, transmitted, and shared in real time. This feature is highly valuable for clinical documentation, staff training, and educational purposes.
The system includes a Full HD camera with 30x optical zoom, delivering live video output through SDI/HDMI. Smooth 1080p/60fps imaging ensures accurate detail reproduction, even in low-light conditions.
The articulated suspension arm with 6 balanced joints ensures stable and precise positioning, enabling effortless adjustments during surgical procedures.
All Surgical multiLED models feature color temperature compensation from 3300 K° to 5000 K° and adjustable light intensity via the control panel.
The Endo mode function provides dedicated illumination for endoscopic procedures, with selectable intensity and color temperature.
Light intensity is displayed via a v-meter bar on the control panel.
The total reflection optical system, developed using CAD/CAM technology, ensures an illumination depth of up to 1300 mm.
Colour temperature (k°) | from 3300 to 5000 |
Colour rendering index (Ra) | >95 |
Illumination depth (mm) | ≥1300 |
Total irradiance (W/m2) | 426 |
Bright field size (mm) | 160 ~ 280 |
LED bulb lifespan (h) | 50,000 |
Power supply (V/Hz) | AC110-240v, 50/60Hz |
Total energy absorption (W) | 80 |
Maximum installation height (Metres) | 2.9 |
Certification | 93/42/EEC – 2007/47/CE – IEC62321 |
Compliance with |
(UE) 2017/745 |
Zoom | 30X Optical |
Resolution | Full HD 1080p 60 fps |
Sensor | CMOS 1/2.8″ |
Image Stabilization |
Yes |
